Cicada serenade

A Spotlight Specimens special for Oxford Festival of Nature

by Leonidas-Romanos Davranoglou, DPhil student, Animal Flight Group, Department of Zoology, University of Oxford

Anyone walking on a summer day in hot places such as the Mediterranean or the tropics will have heard cicadas singing. Cicadas actually are among the loudest of all animals, singing at up to 120 dB – as loud as a passing freight train. In fact, you can damage your ear if a particularly loud species starts singing next to your head.

Some countries even have health and safety policies which prevent people from working outdoors when cicadas are singing. If a single cicada can sing that loud, you can imagine what a forest filled with them sounds like!

Tropical cicadas from the Museums' collections

Tropical cicadas from the Museums’ collections

Only male cicadas sing, primarily to attract females, much like a Romeo singing to his Juliet. Females are mute, but they respond to males of their liking by flicking their wings, generating a loud click. Entomologists often mimic the female response by snapping their fingers under a tree containing cicadas. In this way, they can collect males eager to mate, which would otherwise be too high in the tree to reach.

An unpleasant parasitic fungus capitalises on this arrangement: The fungus basically consumes the innards of the male cicadas, causing their private parts to fall off – in effect castrating them. A castrated male may stop singing and as a result, other males try to mate with it, and in this way the fungus is transmitted from male to male.

But how do these famous (or notorious, if you find them annoying) cicadas produce these incredible sounds? This has remained a mystery since the time of the ancient Greeks, who admired these animals. But the matter was settled through a collaboration between Oxford University and Australian scientists. The physical process is not too complex and you can get a good idea how it works by using an empty plastic bottle.

Cicadas have a unique membrane on the sides of their abdomen called the tymbal membrane, which is strong but flexible. Internally, two huge muscles attach to this membrane. When the muscles contract, they pull and buckle the membrane inwards to produce a strong popping sound. You can imitate this by squeezing an empty plastic bottle in and out. Speed up this process by a few hundred buckles per second and you get a cicada’s song.

PowerPoint Presentation

Dorsal view of the abdomen of the cicada Cicadetta flaveola, showing the two membranes on the sides of the abdomen (tymbal membrane).

Lateral view of a dissected cicada, Tibicen plebejus. The huge muscle attaches to the tymbal memembrane, and pulls it inwards to generate a loud click. Note that after the large muscle, the abdomen is largely hollow.

Lateral view of a dissected cicada, Lyristes plebejus. The huge muscle attaches to the tymbal memembrane, and pulls it inwards to generate a loud click. After the large muscle, the abdomen is largely hollow.

Producing sound however, is not enough. Just like we have to talk with a particular loudness so people can hear us, cicadas must find ways of amplifying their sound, so females can hear them from very far away. The way cicadas achieve this is via something called Helmholtz resonance. You can create this phenomenon by blowing air across the top of the empty bottle you just used to create the pop.

Blowing across a bottle produces sound due to the behaviour of air when it is confined in a container with an open hole. The abdomen of cicadas forms a Helmholtz resonator as well: it is completely hollow, and two openings on the underside, called tympana, act as the top of a bottle and radiate sound in the same way.

Ventral view of a dissected cicada, Tibicen plebejus. The large aperture is the tympanum, which acts as the amplifier for the cicadas' song. The hole of an empty bottle behaves in the same way when you blow air over it.

Ventral (underside) view of a dissected cicada, Lyristes plebejus. The large opening is the tympanum, which acts as the amplifier for the cicada’s song. The hole of an empty bottle behaves in the same way when you blow air over it.

The singing habits and unique anatomy of the cicadas are perhaps best summarized in a quote by 19th-century entomologist Jean Henri Fabre, who, poetically as always, said:

Assuredly one must be passionately devoted to music thus to clear one’s internal organs in order to make room for a musical box!
